5 axis rotary stone cnc router 5axis wood carving machine 4axis wood carving machine

Option: 4 Axis

We are factory professional produce 3 axis,4 axis,5 axis cnc machines,cnc laser,3D scanner etc.
Including all kinds of 2d,3d flat decoration products and rotary 3d sculptures,pillars,moulds etc.
Machining on wood,foam,stone,plastic,PVC,composite boards,acrylic,glass,aluminum etc.
Welcome for your inquiry and visit our factory!

3d sculptures cnc router,4 axis cnc router engraver machine

it can process different kinds of small and big 3d sculptures statues,also can process plane materials !!

Model: JCT1530L
5 Axis Rotary Stone CNC Router 5axis Wood Carving Machine 4axis Wood Carving Machine

5 Axis Rotary Stone CNC Router 5axis Wood Carving Machine 4axis Wood Carving Machine


>> Technical parameter

X Y Z A C working size

1500 x 3000 x 500mm x180°
1300 x 2500 x 500mm x 180° (Option)

Rotary working size

0-1000mm diameter/ 2500mm length

Lathe bed structure

T-extrusion, Thick Steel frame

Table surface

Aluminium T-slot with clamps

X Y structure

Rack and pinion, HIWIN linear square rail

Z structure

Ball screw, HIWIN linear square rail

Resolution

±0.02mm

Reposition accuracy

±0.05mm

Max. rapid

0-60000mm/min

Max. working speed

0-30000mm/min

Spindle power

9kw air cooling spindle

Spindle speed

0-24000RPM

Working mode

Japan YASKAWA Servo motor and driver

Command code

G code(*uoo,*nc,*mmg, *plt)

Operating system

4 or 5 axis NcStudio (WeiHong) or Syntec control system

Collet

ER32

Oil system

Yes

5th Axis

The spindle can swing forward and backward


 >> Technical features

a) all machine parts adopt high configuration and top quality fromall over the world,to make
    machine with high performance and durability.
b) with a big rotary device, can process different kind of 3d sculptures,statues,columns.
c) with a flat table, can process plane materials.

 >>Advantages

1) Big rotary axis for carving life-size foam wood stone sculptures statues figures and other column / round  /

    cylinder / square

2) Removeable table: When you carve flat / plane material, you can install the table

3) Powerful PowerMill software for complex programs

4) Easy-to-use Ncstuidio or Syntec controller

5) 5th axis: The spindle can move forward and backward in different angle

>> What can be made by this machine
It can process many materials,like foam,woods, MDF, Composite boards
PVC, Rigid plastics, Acrylic Sheets, Glass, Organic glass, Aluminum plates.,etc.

5 Axis Rotary Stone CNC Router 5axis Wood Carving Machine 4axis Wood Carving Machine
5 Axis Rotary Stone CNC Router 5axis Wood Carving Machine 4axis Wood Carving Machine
5 Axis Rotary Stone CNC Router 5axis Wood Carving Machine 4axis Wood Carving Machine
5 Axis Rotary Stone CNC Router 5axis Wood Carving Machine 4axis Wood Carving Machine

>> Optional device: 3d scanner

5 Axis Rotary Stone CNC Router 5axis Wood Carving Machine 4axis Wood Carving Machine

>> Customer visiting & training
5 Axis Rotary Stone CNC Router 5axis Wood Carving Machine 4axis Wood Carving Machine

>> Certifications:
5 Axis Rotary Stone CNC Router 5axis Wood Carving Machine 4axis Wood Carving Machine



>> Customer feedback

5 Axis Rotary Stone CNC Router 5axis Wood Carving Machine 4axis Wood Carving Machine
>> Factory
5 Axis Rotary Stone CNC Router 5axis Wood Carving Machine 4axis Wood Carving Machine

Linyi CHAODA International CNC Technology Co., Ltd was established in 2002 and covers
40000 Square meters.we have experienced and professional engineers who devote themselves
to machines' research, development, production, and after-sale service. Our machines have won
praise from customers worldwide and with very good reputation in this field.


Contact us as below, we will offer you our best price !!
