Model

SIGN-2040

X, Y Working size

2000*4000mm

Z feed Height

300mm

Table Surface

Vacuum table

X, Y Structure

Rack and Pinion Drive, TBI Linear Square Guide Rail

Z Structure

TBI Linear Square Guide Rail and Ball Screw

Max. Power Consumption

(Without spindle) 2.0Kw

Max. Rapid Travel Rate

33000mm/min

Max. Working Speed

25000mm/min

Spindle Power

9.0KW HQD ATC spindle

Spindle Speed

0-24000RPM

Drive Motors

Yaskawa servo motor and driver

Working Voltage:

AC220V/50/60Hz

Command Language

G code

Control System

SYNTEC 6MB

X,Y,Z repositioning Accuracy

±0.01mm

X,Y Resolution

 <0.01mm

Software

Artcam

Running Temperature

0 degree - 45 degree

Relative Humidity

30% - 75%

Optional Parts

Rotary system,

Panasonic Servo motors
